Mec Micro 19 - Page 75

Page 71 Micro 19 - Service & Parts Manual
November 2019Section 17 - Electrical System
Item Part Number Description Qty.
1 42481 Harness, ECU Modular 1
2 42482 Harness, Electrical Component 1
3 42483 Harness, Platform Control Box 2
4 42484 Harness, Drive Motor 1
5 41919 Battery Harness 1 1330 Pump Motor Negative 1
6 41921 Battery Negative Harness 1330 Pump Motor Positive 1
7 41917 Harness, DC Contactor 1330 Drive Controller 1
8 42485 Harness, DC Contactor 1
9 42486 Harness, Fuse 1
10 42487 Harness, Battery Positive 1
11 42488 Harness, Battery 1
12 42489 Battery Negative Harness 1
13
41889 ECU Modular - From Serial 16900000 - 16900460 (Refer to Page 50) 1
42435 ECU Modular - From Serial 16900461 - Current (Refer to Page 50) 1
14 42434 Ground Control Panel (Refer to Page 50) 1
15 41334 Relay (Refer to Page 50) 1
16 41070 Hour Meter (Refer to Page 50) 1
17 42419 Drive Motor (Refer to Page 42) 1
18 42421 Drive Motor (Refer to Page 44) 1
19 42496 Motor Controller 19 (Refer to Page 48) 1
20 42424 Motor (Refer to Page 48) 2
21 41331 DC Contactor (Refer to Page 48) 1
22 42432 Fuse (Refer to Page 48) 1
23 41065 Power Switch (Refer to Page 48) 1
24 REF Battery Group 31 AGM 115 AH (Refer to Page 48) 2
25 41254 Charger (Refer to Page 48) 1
26 REF Platform Controls (Refer to Page 62) 1
27 -- Not used --
28 -- Not Used --
29 41098 Level Sensor (Refer to Page 34 or 36) 1
30 42400 Lift Up Limit Switch (Refer to Page 34) 1
31 42402 Lift Down limit Switch (Refer to Page 34) 1
32 41197 Limit Switch, Pothole (Refer to Page 34 or 36) 2
33 41075 Horn (Refer to Page 48)
1
34 41074 Buzzer, Alarm (Refer to Page 48) 1
35 42422 Hydraulic Power Unit (Refer to Page 48) 1
36 41310 Beacon (Refer to Page 34 or 36) 1
REF - Reference
