MechMaxx SG24 - Flywheel Tooth Torquing

14
www. mechmaxx.com
TORQUE ADAPTER
FLYWHEEL TOOTH TORQUING
FLYWHEEL TOOTH TORQUING
Prior to each operation, be sure to tighten all 34 teeth
using a ring spanner with a 24 mm socket.
Slide the ring spanner over the nut and torque the nut by
rotating it clockwise. Repeat the process for all four (4)
of the outward-pointing teeth.
