SPECIFICATIONS
OVERALL DIMENSIONS
2
www. mechmaxx.com
SPECIFICATIONS
Flywheel Thickness
Model
3/4 in
Flywheel Diameter 24 in
SG24
Carbid Tip 34 pcs
Carbid Tip Material YG11C
Tip Holder Material
42CrMo
PTO Shaft (Included Shipping)
PTO HP Required
1-3/8” 6 Spline Tractor and Implement Ends PTO
Driveline Shaft with Slip Clutch
15–45 HP
Friction Torque Limiter (Slip Clutch) Included
Mounting 3 point hitch Cat. 1 (Quick attach compatible)
PTO Input
Max. Torque
540 RPM
1200Nm
PTO Shaft Weight 44 lbs
Dimensions 29 x 37x 38 in
Packing Iron frame + Carton
Weight (N.W/G.W.) 450/563 lbs
802mm
31.5”
705mm
27.7”
1081mm
42.5”
