(3)2.4 inch TFT color display: with a resistance to touch. The screen resolution is
320X240 with FPC welded at the circuit board.
b. The main testing points: none
c. Number and definition of the sockets
No.
Socket
PIN No.
Description
Explanation
1
J1
24
Socket to connect the
alarm light board
Connect J1 in the alarm light
board
2
J2
24
Socket to connect the
power board
Connect J2 in the power board
3
J3
8
Socket to connect the
button cover
Connect the button cover
2.4.8 Button cover
a. Button cover introduction
(1) Buttons: [ON/OFF] for switching on/off,[HOME] for returning to main
screen,[OPEN] for opening the pump door.
(2) Indicator light: 2 LED lights of green and yellow are built in the cover. While the
machine is power off and AC inputting, yellow light works. While the power is on, green
light works. The indicator lights works as follows:
State of SYS-6010
State of yellow light
State of green light
Power off and no AC
OFF
OFF
Power off and AC
ON
OFF
Power on
OFF
ON
Remark: “ON” means light is on, “OFF” means light is out.
b. The main testing points:none
c. Number and definition of the socket
No.
Socket
PIN
No.
Description
Explanation
1
FPC
block
8
Socket to connect SYS02
board
Connect J3 in the SYS02 board
2.4.9 Alarm light board
a. The circuit introduction
3 groups of LED lights are installed in the alarm light board. The colors are green,
yellow and red, each group of 2 LED lights, to indicate the states of working, high, middle
and low level alarm. The states of indicators are as follows:
State of indicators
Meaning of lights indicate
Green light flashing
The infusion pump is normally working, flash frequency
indicates infusion speed
Yellow light illuminating
Lower level alarm
Yellow light flashing
Middle level alarm
