MEDCAPTAIN SYS-6010 - Technology Alarms and Troubleshooting; Common Device Faults

33
1
ERR-0003
Door position fault
Replace the hall switch board
2
ERR-0004
Pressure sensor is falling or
abnormal pressed.
Reinstall the tube again or
Replace the pressure sensor and
the infusion pressure speed auto
driving board.
3
ERR-0005
Stepper motor speed error
Replace the hall switch board or
Replace the stepper motor
4
ERR-0006
The 5V power supply
voltage or 18V motor drive
voltage is abnormal.
Replace DC/DC power board
5
ERR-0007
Pump tablets fault
Replace the peristaltic pump
tablets position test board
6
ERR-0008
SYS02 board and power
board correspondence fault
SYS02 board damaged or the
cable disconnection
7
ERR-0009
System fault
Update software
8
ERR-0010
EEPROM fault
Replace the SYS02 board
5.2 Common faults and Troubleshooting
The device fault checking:
NO.
Failure phenomenon
Cause
Solution
1
Can not turn on pump
No AC power
Check AC power, panel indicator,
replace battery
Key panel failure
Replace panel
FPC cable failure
Replace FPC cable
Power board failure
Replace power board
2
Black screen and alarm
indicator is off
No AC power
Check AC power, panel indicator,
replace battery
FPC cable failure
Replace FPC cable
SYS02 board failure
Replace SYS02 board
3
Black screen and alarm
indicator is on
FPC cable failure
Replace FPC cable
SYS02 board failure
Replace SYS02 board
Touch screen failure
Replace touch screen
4
White screen
Touch screen failure
Replace touch screen
5
Touch screen is no
Touch screen not calibrate
Calibrate touch screen
