MEDCAPTAIN SYS-6010 - Software and General Specifications; Technical Specifications

19
phases driving. The working voltage is 24V.
d. Number and definition of the socket
No.
Socket
PIN
No.
Description
Explanation
1
/
4
Socket to connect the
infusion pump pressure
&speed detection board
Connect J9 in the infusion pump
pressure &speed detection board
2.5 The software
The SYS-6010 consists of 3 softwares.
The power board software: to obtain all kinds of sensor signals, control and calculate
of the stepper motor, obtain self-testing information and process the alarm information. It
corresponds with the UI software and power failure alarm software.
The UI software: to be used in the monitor interface display, button operation, function
setting and operating of the human-computer interaction, data storage, nurse call and
voice function. It corresponds with the power board.
The power failure alarm software: under the situation of built-in battery failure and
external power is cut-off, to control the device to output a light and voice high-level alarm.
It corresponds with the power board.
2.6 Specifications
Power supply
AC power supply: AC 100-240V,50/60 Hz, power,
consumption 25 VA
External DC power supply: DC 12 V
Internal battery: lithium battery 11.1 V 1500 mAh
Time of continuous use: no less than 5 hours (for infusion at 25
mL /h with a new battery)
Compatible IV sets
All disposable infusion sets of 20d/mL and 60d/mL conform to the
standards.
Infusion mode
6 infusion modes: rate, drop, time, standard weight, weight,
multi-rate
Infusion setting
range
0.1-1200.0mL /h or (1-400d/min) (20d/mL IV set)
0.1-200.0mL /h or (1-200d/min) (60d/mL IV set)
Least increment of 0.1 mL /h(or 1d/min)
Total volume
display
0.0-99999.9mL
Accuracy
±5%
Purge operation
400.0mL /h (20d/mL IV set)
200.0mL /h (60d/mL IV set)
Bolus operation
35.0-1200.0mL /h(20d/mL IV set)
