SYS02 module board (figure 6.3-7/code name 3) lightly.
10)Use phillips to remove the 2 PB2.3 tapping screws in the alarm lamp board and take
down the alarm lamp board and lamp shadelightly.
11)Take out the SYS02 module board and display screen lightly.
Attention: put the display screen upward, avoid scratching or pollute it.
12) Use phillips to remove the 4 machine screws in the 2 door catches (figure 6.3-7/code
name 11) and take down the 4 M3 spring washers.
Attention: do not miss the plastic chips under the door catch,2 pieces of each door
catch.
13) Take down the door catch.
14) Tear down the membrane (figure 6.3-7/code name 14) from the panel (figure
6.3-7/code name 8).
Note: the installation operation method: Reverse operation according to the steps above.
6.4 Installation
7 The Safety Test
Warning!
The electric and safety test is used to check the abnormal electric hazards.
If the hazards can not be discovered timely, it might cause injury to the
patient and operator.
The equipment of the electric and safety test adopts the safety analyzer,
maintainers should master the usage.
The electric and safety test completely complies with the standard of
IEC/EN60601-1.
Please conduct the electric and safety test in a normal circumstance
(including temperature, humidity and atmosphere).
The electric and safety test in the chapter takes the example of 601 safety
analyzer. Different brands of the safety analyzer might have a different
analysis.
If the electric and safety test fails, please contract our after-sales service
engineers.
7.1 Electric Leakage Test of Enclosure
1. Connect the 601 safety analyzer to 264 VAC/60 Hz power source.
2. Connect the applied part of the tested equipment by using the applied part
connection tooling. The SUM end of the connection tooling for applied part is
connected to the RA end of the safety analyzer.
