Medeli SP40A - General Guide; Front Panel; Left Panel

General Guide
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
10
11
12
13
14
15
POWER SWITCH
MASTER VOLUME
DUAL
DSP
TOUCH
RECORD
TRACK A
TRACK B
REPEAT
METRONOME
TRANSPOSE +/-
TEMPO +/-
DEMO ALL
RECORD
- PLAY
- STOP
DEMO
- SELECT
- START/STOP
SUSTAIN PEDAL
SOFT PEDAL
AUX.OUT (L /MONO)
AUX.OUT (RIGHT)
PHONES(1,2)
MIDI IN
MIDI OUT
AUX.IN
POWER SUPPLY JACK ( DC in 12V)
16
VOICE TYPE & DEMO SONG SELECT
0 - PIANO 1
1 - PIANO 2
2 - E.PIANO 1
3 - E.PIANO 2
4 - HARPSICHORD
5 - VIBES
6 - STRINGS ENSEMBLE
7 - CHORUS
8 - JAZZ ORGAN
9 - CHURCH ORGAN
LED
- TEMPO
- SONG
- TRANSPOSE
17
3
1.FRONT PANEL
2.LEFT PANEL
8 9
9
