MEDENUS R 100 User Manual

18
© 11.2023
FB spring series for RS250 DN 150 - DN 200
and RS251 DN 080 - DN 100
shown RS250 DN 200 with FB707
70mm-130mm
Spring data Specific command range W
ds
[mbar]
Spring no. Color [RAL] RE 275-2 RE 385 RE 485
FB 701 6018 - - 18 - 22
FB 702 9006 - - 21 - 25
FB 703 5015 - - 24 - 31
FB 704 4002 - - 28 - 36
FB 705 7037 - - 33 - 44
FB 706 9005 - - 41 - 56
FB 707 3020 - - 51 - 71
FB 708 9010 - 150 - 167 65 - 94
FB 709 7016 350 - 450 165 - 215 82 - 118
FB 710 6010 397 - 596 212 - 285 105 - 155
FB 711 2002 542 - 814 280 - 390 140 - 209
FB 712 7035 742 - 1078 385 - 520 188 - 275
FB 713* 5010 977 - 1442 515 - 671 246 - 369
FB 714* 1028 1245 - 1878 661 - 850 311 - 450
FB 715* 6018 1547 - 2469 - -
FB 716* 3020 2136 - 3000 - -
