MEDENUS R 100 - Parts for Maintenance Work; Main Diaphragm and O-Ring R100; R100-U; Valve Plate R100; R100-U (Standard E.g. VT-102; Viton E.g. VT-102-V)

23
© 05.2022
11.3 Parts for Maintenance Work
Main diaphragm and O-ring R100 / R100-U
Item
no.
Name Quantity
pcs.
R100 (-U) / 050; R100 (-U) / 080;
R100 (-U) / 100
R100 (-U) / 150;
R100 (-U) / 200
RE 160 RE 275 RE 390 MB RE 390 GMB RE 275 RE 385 MB RE 385 GMB
15 O-ring 1 O-041 O-042 O-042 O-041 O-042 O-042
16 Diaphragm 1 M-112 M-132 M-152 M-162 M-132 M-152 M-162
Main diaphragm set
order number:
M-112 MS-132 MS-152 MS-162 MS-132 MS-152 MS-162
Valve plate R100 / R100-U (standard e.g. VT-102 / Viton e.g. VT-102-V)
Item no. Quantity pcs. Valve (6.1) Valve (6.2) R 100 / 050 R100 / 080 R 100 / 100 R 100 / 150 R 100 / 200
6.1
6.2
2 27.5 27.5
VT-003
VT-101-V
2 32.5 32.5 VT-005
2 42.5 42.5 VT-006
2 45 45
VT-102
VT-102-V
1
45
VT-102
VT-102-V
50
VT-103
VT-103-V
2 60 60
VT-104
VT-104-V
1
60
VT-104
VT-104-V
65
VT-105
VT-105-V
2 65 65
VT-105
VT-105-V
VT-105
VT-105-V
2 90 90 VT-106
2 95 95
VT-107
VT-107-V
1
95
VT-107
VT-107-V
100
VT-108
VT-108-V
2 100 100
VT-108
VT-108-V
2 125 125
VT-109
VT-109-V
1
125
VT-109
VT-109-V
130
VT-110
VT-110-V
2 130 130
VT-110
VT-110-V
