TECHNICAL INFORMATION
Power Supply
Transformer manufactured to IEC – EN60742
Output – Saw 40 VDC
Enclosure –to IEC529, DIN40050
Protected to IP65
Protection- Electronic Current Limiting
Device Double Pole Fused
Constructed –to IEC60601-1
Weight 1.7kg
Input voltage – 230Vac or 110 Vac
Cable 4.0m tted
Vacuum Unit
Motor – Rated 750 Watt
Container Capacity – 7.0 litre
Air Volume Open (max) – 90 litres/sec
Max Vac Closed – 1650mm WG
Filtration-99.997% at 0.6 micron
Dimensions – Height 940mm including handle
Width 530mm Chassis Base
Weight 11.5kg
Audio Output – 66Db at 1 metre
Hand Piece
Motor –DC Permanent magnet
Speed –no load 13200 cycles per min
Current – no load 40Vdc 0.75amp
Typical load 1.5 amps
Construction – Anodised Aluminium body with
5 bearing sealed mechanism
Protected to – IP67
Audio Output – 37 dB (A) no blade
Vibration Value – 4.12 m/s²
Weight – 1.3kg
