Fig5.2.2
Screw
loose, use a hex driver to tighten the screws
on both sides (see 5.2.2).
5.2.3 Rail cover removal
instructions
1 Place your hand on the rail cover
2 Pull the rail cover outwards to see an
obvious gap.
3 Move the rail cover in the direction of the
arrow shown
4 If the mid cover area is detached , the
disassembly is successful.
5 The false example one
6 The false example one
