Slit Lamp Microscope USER MANUAL
17 / 29
from 100V to 240V. The power switch
(see Figure 2.2.7) can be turned on with
one short-press, short-pressed again to
hold, and long press for 3 seconds to turn
off all power.
Fig2.2.10
Fig2.2.7
2.3S390L Digital Module Set
installation procedure
1.Align the digital module set splitter mount
to the slit lamp main body, and rotate the
splitter to the right to the position could lock
splitter. Then install the binocular tubes on
the splitter in the same way.
