Medline MDS86845W User Manual

4
MDS86845 Series (PIC-00311)
Revised: 12/28/2018
A. Handgrips
B. Adjustable
Handlebar
C. Handlebar Height
Adjust Lock
D. Back Rest
E. Padded Seat
F. Handlebar Folding
Mechanism
G. Adjustment Knob
H. Brake Handle/Lock
I. Brake Cable
J. Triangular
Knob Screw
K. 8" (203 mm)
Front Wheels
L. 8" (203 mm)
Rear Wheels
M. Brake Shoe
Rollator Components
1 Rollator Frame
2 Front Wheels
2 Handlebars
2 Rear Wheels
4 Triangular Knob Screws
1 Backrest
1 Seat
1 Bag
Assembly Instructions
Assembled Rollator
Figure 1
Assembled Rollator
A
B
C
D
I
E
J
G
F
H
FRONT
BACK
M
I
L
K

Medline MDS86845W Specifications

General

Brand	Medline
Model	MDS86845W
Category	Mobility Aid
Language	English
