Megger DET24C - Page 6

6
Figure 3: DET14C / DET24C Instrument Bottom
View
1. Wrist strap loop
2. IrDA window
Figure 4: DET14C / DET24C Instrument Display
View
Save Tick = set
Open Cross = not set
Delete Warning refer to user guide
IrDA download Signal noise detected
Alarm Less than
Filter More than
Battery
Hold
Date formats
Hours, minutes, seconds
Clamp open
1
2
