10
1.4 Technical Data
a. Mains voltage: 230 V + 6 / - 10 %
b. Mains frequency: 45 – 60 Hz
c. Operating current: 16 A (max.)
d. Power rating: 3.5 kVA
e. Circuit breaker: 10 A
f. Output voltage: 0 – 250 V
g. Meter U: kV-Meter 0 … 60 kV
or 0 … 80 kV
or 0 … 110 kV
h. Meter I: mA-Meter 0.5 / 50 mA
i. Timer: 1 – 99 min
l. Operating temperature: - 20 bis + 55
0
C
k. Storage temperature: - 40 bis + 85
0
C
l. Protection class: IP 22
m. Weight HSW 3-2: 26 kg
n. Dimensions (L x B x T): 520 x 255 x 320 mm
p. Versions: stand-alone and table version
