1.3 High Voltage Test Configurations
The HSW 3-2 can be used as control unit for the following high
voltage test sets:
HPG 35-AC 0 – 35 kV
RMS
AC
HPG 58-AC 0 – 58 kV
RMS
AC
HPG 78-AC 0 – 78 kV
RMS
AC
HPG 50-H 0 – 50 kV DC (0 – 35 kV
RMS
AC)
HPG 80-H 0 – 80 kV DC (0 – 58 kV
RMS
AC)
HPG 110-H 0 – 110 kV DC (0 – 78 kV
RMS
AC)
HPG 50-D 0 – 100 kV DC (0 – 35 kV
RMS
AC)
HPG 80-D 0 – 150 kV DC (0 – 58 kV
RMS
AC)
CAUTION
Depending on the input voltage it is in some
cases
possible to generate a higher output voltage as the unit
has been design
ed for. This area is marked on the
scalar. NEVER exceed the maximum design output
voltage (as stated above)
as this could potentially
damage the system.
