Displayed Test Results
• MK value
• Lx/L relative distance of fault compared to the cable length
• Rx wire resistance between the instrument and fault
• 2Rx double wire resistance between the instrument and fault
• Rl loop resistance
• FaE fault resistance
• DTS (calculated of the cable parameters and Rl)
• DTF (calculated of the cable parameters, Rl and Lx/L)
To change the cable type
• Press the C.LIBR (F6) key
• Select a new cable type and press ENTER
• Press ESC
To change the cable temperature
• Press the TEMP.(F4) key,
• Type in the temperature value and press ENTER.
When the cable length is known
• Press the LENGTH (F5) key
• Type in the length value and press ENTER
For returning to the normal display
• Press the LENGTH (F5) key
• Press ENTER
To save the test result press the SAVE (F1) key.
