Megger LRCD200 series User Manual

6
LCD DISPLAY FRONT PANEL
Supply connection indicators
L-PE, L-N, N-PE
Front panel cover
(folded under
instrument)
Backlight
On/Off (220)
PFC (200/210)
Test lead
connections
LCD Display
Neck strap
slots
0º/180º
Lock(220)
Test button
Ranges
Measured results
Phase rotation
Fuse blown
Mains noise
Battery status
Refer to User Manual
Touch
voltage
bargraph
display
RCD test
type
indicator
RCD type
selector:
AC
AC Selective
DC
DC Selective
PFC
(220)
RCD range select:
10mA
30mA
100mA
300mA
500mA
1000mA (220 only)
Test selector:
1
/
2
x I RCD trip time (210/220)
1 x I RCD trip time
5 x I RCD trip time (210/220)
Ramp
V - AC RMS
Hz - Frequency
Phase ROT (220 only)
Auto RCD testing (220 only)
z
