REAR PANEL CONNECTIONS CONTROL PADS
LRCD200
LRCD220
Lid open/closure
1. Open lid by lifting up front panel tab (1).
2. Fold-away underneath instrument (2 & 3) and push into retaining slot
(4).
LRCD 200/210
LRCD220
7
Warning
Read user guide
Warning
Read user guide
Earth connection or 2nd Phase connections (220 only)
Earth connection
Phase connection
Phase connection
Mains plug test
lead connector
Mains plug test
lead connector
