Symbols used on the instrument are:
F Caution: risk of electric shock
G Caution: refer to accompanying notes
t Equipment protected throughout by Double
Insulation (Class II)
c Equipment complies with current EU directives.
CONTENTS
3
SAFETY WARNINGS 2
INTRODUCTION 4
Power cord and charging the batteries. 4
QUICK START 5
INSTRUMENT CONTROLS AND INDICATORS 6
On / Off Button. 8
PI / IR 8
Voltage Adjust 8
Timer Adjust 8
Test Button 9
Display Button 9
Test Terminals 9
RS232 socket 9
Recording to on board memory 10
Recording to a PC 10
Downloading Results 10
Deleting Test Results 10
HV ON led 10
Battery Condition Indicator. 11
Voltage Indicator 11
Time Indicator 11
The Guard Terminal 11
SPECIFICATIONS 12
REPAIR AND WARRANTY 13
