Megger MIT510 - Instrument Assembly and Disassembly

AF008-02-1201
4
Number
Issue
Date
CN Number
6
1
7
2-
999
2
17-01-07
22933
Compiled
By:
S.Mynott
Date
Compiled:
08/08/06
MIT5XX/10XX
1
st
Used On:
SERVICE MANUAL
The insulation tester models differ in the following ways:
a. The MIT520 has ‘USB’ capability and additional keys for added functionality.
b. The MIT1020 has ‘USB’ capability and a different ‘HV’ Board from the ‘5 series’ models. It also has
additional keys for the added functionality.
c. The S1-552 and S1-554 are the same build as the MIT520 and MIT1020 respectively, but provide a
higher output current (selected in firmware).
d. The S1-554 and S1-1054 are the same build as S1-552 and S1-1052 respectively, but are fitted with
a different measurement board to provide increased noise current filtering. Additional filtering menus
are also available in the firmware
Section 2 Instrument Assembly and Disassembly.
Page
2.1 MIT510/520 & 1020 Assembly. 5
2.2 MIT510/520 & 1020 Disassembly. 6
2.3 MIT510/520 & 1020 Assembly Numbers 6
2.4 MIT510/520 & 1020 Drawings. 8
2.5 Interconnect Diagrams. 10
