Megger MIT510 - Page 57

AF008-02-1201
57
Number
Issue
Date
CN Number
6
1
7
2-
999
2
17-01-07
22933
Compiled
By:
S.Mynott
Date
Compiled:
08/08/06
MIT5XX/10XX
1
st
Used On:
SERVICE MANUAL
Section 6 Component Layouts Page
6.1 Display Board 58
6.2 Keypad Board 59
6.3 Interface 10 & 20 Board 60
6.4 Isolated Interface Board 61
6.5 Power Supply Board 62
6.6 Measurement Board 63
6.7 5KV Generator Board 64
6.8 10KV Generator Board 65
