AF008-02-1201
78
Number
Issue
Date
CN Number
6
1
7
2-
999
2
17-01-07
22933
Compiled
By:
S.Mynott
Date
Compiled:
08/08/06
MIT5XX/10XX
1
st
Used On:
SERVICE MANUAL
7.8 10Kv Board BOM - circuit diagram 6270-301 issue 6
10kv Board Bill of Materials
Value Part Reference PARTNUM
100n C1 C8 C11 C12 C39 27889-836
10n C3 27889-890
470u C4 C40 26970-080
220u C5 C6 27889-700
10n C7 27889-809
220u C9 C10 27889-869
47u C13 26970-103
47n C14 C15 C16 C17 C18 C19 C20 C21 C22 C23 C24 26970-087
15nF C25 26970-174
470nF C26 C28 32000-042
2.2n C27 C34 32000-006
10nF C29 C36 32000-025
100n C30 C32 C43 32000-029
100nF C31 C37 32000-004
470p C33 32000-002
100pF C35 32000-030
33nF C38 32000-019
1n C41 32000-027
10uF C42 32000-022
BZX79C7V5 D1 28862-891
BYW29E-100 D2 28920-073
BZT03C18 D3 D26 28920-024
1N4002 D4 D5 D7 D21 28862-927
BZT03C82 D6 29500-003
BY203-20S D8 D9 D10 D11 D12 D13 D14 D15 D16 D17 D18 29400-019
BZX79C10 D19 28920-018
HLMP1340 D20 28920-085
LL4148 D24 (D22 D23 not fitted) 31000-002
BYV10-30 D25 28920-067
BZX84C10 D27 31400-006
FS1,FS2 25950-016
CA3240E IC1 20000-020
CA3140M IC2 30000-013
LM339 IC3 31000-005
LM311 IC4 31000-012
INDUCTOR L1 L2 L3 35000-026
LINK DUMMY LKD1
PL1 PL3 PL6 PL7 PL8 PL9 25424-932
PL2 PL10 25257-668
PL4 PL5 25960-045-03
8.2K R1 R4 R18 R19 R20 R21 R22 R23 R24 R25 R26 R27 R28 R29 R30 R31 R32 26837-148
R33 R34 R35
56K R2 26900-155
47K R3 R5 26900-137
4.7M R6 R7 26837-189
750K R8 26837-066
39K R9 26900-214
6.8M R10 26836-731
5K R11 26950-010
100M R12 R13 26836-558
10K R16 R17 R36 R37 R38 R39 R40 R41 R127 R128 R129 26837-158
10K R43 R46 R44 R49 33000-012
