SERVICE MANUAL
Appendix 4. Spare Parts List.
Comments
Display Window 5110-514
I/O Cover 5210-451 Communication port cover
Rubber Keypad Moulding (MIT51X) 5410-390
Rubber Keypad Moulding (MIT52X, MIT102X) 5410-391
Front Panel Cover 5410-387 Inner grey fascia moulding
Module Housing Cover 5410-389 Interior clear isolation moulding
Module Base Housing 5410-388 Inner grey lower moulding
Shutter cover 5110-512 Retains terminal shutters
Positive & Guard Hv socket connector 5152-174 Positive and Guard terminals
Negative socket connector 5152-313 Negative terminal
Guard Plate 5131-394
Leakage Spring 5160-336
Socket Mount 5410-371
Label Set (MIT52X & MIT102X) 5270-828
Label Set (MIT51X) 5270-827
Label Set (S1-552/1052) 5270-939
Label Set (S1-554/1054) 5270-940
Battery 12V 4.0Ah lead acid 25985-030 See Note 2
Battery lead (MIT5XX & MIT10XX) 6180-454 Fuse 25950-057 required
Battery 5A fuse , 32V fast 25950-057 In line fuse from battery
3.15A(F) HBC 20mm fuse (Power PCB) 25413-280 1 off used per Power PCB
2A (T) 20mm fuse (HV PCB) 25950-016 2 off used per 10kv or 5kv HV Board
500mA Fuse (FF) 30KA 660V 32mm (Meas PCB) 25950-034 1 off used per Measure board
Plug IEC 2-pin panel mtg 25960-117 Mains connector (instrument)
Hv Lead Set (3x3m) 10kv 8101-181
Polypropylene Carry Case 6480-078 Outer carry case
Accessories Bag (MIT5XX & MIT10XX) 6320-243
Quickstart guide (MITX20 & S1-XXX) 6172-919
Quickstart guide (MIT510) 6172-915
PC AT-AT serial link cable (RS232) 25955-025
USB type A to type B cable 25970-041 USB cable
Download Manager software CD 6111-442
User Guide and Quickstart CD (MIT510) 6172-929
User Guide and Quickstart CD (MIT520/1020) 6172-960
User Guide and Quickstart CD (S1-552/1052/554/1054) 6172-988
Keyboard PCB (MIT5XX & 10XX) 6231-716
Power PCB (MIT5XX & 10XX) 6331-804 See Note 2 Mains SMPS. Uses 1 fuse(25413-280)
5KV PCB (MIT5XX) 6430-857 See Note 1 Uses 2 fuses 25950-016
10KV PCB (MIT10XX) 6430-855 See Note 1 Uses 2 fuses 25960-016
Measure PCB (MIT5XX &10XX) 6430-859 See Notes 1, 3 , 4 Uses 1 fuse 25950-034(Guard fuse).
Supply with 2 off cable tie. 25274-417.
Measure PCB (S1-X54) 6430-879 See Notes 1, 3 , 4 Uses 1 fuse 25950-034(Guard fuse).
Supply with 2 off cable tie. 25274-417.
Display PCB (MIT5XX & 10XX) 6430-861 See Notes 1, 2, 4
Serial Interface (MIT51X) 6231-756 Non isolated RS232 output
Serial / USB (MIT52X, MIT102X) 6231-758 Isolated USB & RS232 outputs
Isolation transformer (MIT5XX & MIT10XX) 6231-766 Supply with 1 off cable tie 25945-001.
Supply with 1 off cable tie 25274-417.
10KV transformer (MIT10XX) 6231-715
5KV transformer BM11D (MIT5XX) 6231-629
Cable tie 100 x 2.5mm 25274-417 Used to secure measure board wiring
And isolation transformer wiring
Cable tie 203 x 2.5mm 25945-001 Used to secure isolation transformer
Relay 10KV (MIT10XX) 25980-064 1 off per instrument
Relay SP c/o 250VAC (MIT5XX) 25980-056 4 off per instrument
Mains lead UK/IEC 25970-028
Mains lead EUR/IEC 6180-334
Mains lead US/IEC 25970-002
Windows Calibration Software for Authorised Repairers
Note 1. The instrument must be recalibrated after board exchange.
Note 2. The battery must be recalibrated after board exchange.
Note 3. The Display PCB firmware may need to be updated after board exchange.
Note 4. Boards will be supplied with the most up to date firmware unless specified otherwise. Refer to appendix 3.
