Accessories
7
Supplied with the test set Part No.
Padded protective carrying case with handle and
shoulder strap. 6420-102
4 x 600 ml capacity oil test vessels
Pair of spherical electrodes (fitted) 6220-484
Pair of mushroom electrodes 6220-482
Pair of cylindrical electrodes 6220-483
Oil test set preparation kit 6121-486
comprising:-
two magnetic stirrers
pair of cylindrical electrodes 1 inch. diam.
pair of mushroom electrodes 36 mm diam.
* electrode spacing gauges for 1 mm (0.08 inch.)
25 mm (0.01 inch) and 4 mm (0.16 inch)
Battery charger unit 6331-659
Printer lead, OTS 60PB to 25 way ‘D’ 6340-091
Spare fuse 25413-285
User Guide 6171-585
Supplied as optional extras
Close fitting test vessel lid 6121-402
Pack of 10 reusable / disposable oil test vessels 6220-487
Lead for connection to a vehicle battery via the
cigar / cigarette lighter socket 6231-509
Pair of cylindrical electrodes with 0,5 mm
edge radius † 6220-538
Printer kit 6220-568
Paper roll — 57,5 mm wide, 15 m long, 50 mm diam.
25995-001
Ribbon – Epson part no. ERC-09 (IRC160) 25995-002
Printer lead 6340-091
† The optional cylindrical electrodes with a 0,5 mm edge radius do not meet the ASTM D877
specification. They give a higher breakdown value than the standard cylindrical electrode which will allow
results to be compared between instruments with a similar electrode design.
* The new spacer gauges are no longer big enough to have the diameter marked on them. They now
have a series of grooves cut into them to state the difference between them which are as follows:
1 ring - 1mm
2 rings - 2mm
3 rings - 2.5mm
4 rings - 4mm
