Safety Warnings 2
General Description 4
Applications 7
Specification 8
Accessories 9
Operation 10
Warnings 10
Precautions 10
Preliminary procedure 11
Setting the display options 12
Current injection and IDMT testing 12
Manual testing 13
IDMT Forward test 14
IDMT Runback test 15
IDMT Dual test 16
Auxiliary voltage testing 17
Other messages 18
Guidance in Choice of Test Leads for Current Carrying Capacity 19
Duration Tests 20
Circuit Description 21
Sicherheitshinweise 24
Betriebsanleitung 25
Repair and Warranty 36
Components List 37
Illustrations
Figure 1 PCITS 600/2 and PCITS 2000/2 6
Figure 2
Principle of primary current injection testing 8
Figure 3
Principle of secondary current injection testing 8
Figure 4
The main menu showing the testing options available 12
Figure 5
The 'CURRENT' testing options screen 13
Figure 6
The 'AUX VOLTS' testing options screen 18
Figure 7a
Guidance for cross sections and lengths of cables 19
Figure 7b
One - shot Test Duration PCITS600/2 and PCITS200/2 20
Contents
3
