8 HOW TO OBTAIN THE DESIRED CURRENT
▪ The amount of regulation needed can be obtained by
subtracting the current value (A) obtained in step 2 above
from the desired current.
▪ Calculate the number of TORKELs required for the current
regulation.
4. Are all of the TXLs needed?
If the total load-providing capability of the TORKEL(s)
exceeds the amount of regulation needed by a wide
margin (as set fort in step 3 above), you can perhaps
conduct the test with fewer TXLs. If this margin is
wider than the current through one of the TXLs at the
final voltage, this TXL is not needed.
Note Discharge is from 2.15 V to 1.8 V per cell
TORKEL 910
Systems TORKEL 910 and TXL 830 (Pos 2)
12 V battery (6 cells)
Max constant current No. of TORKEL 910 No. of TXL 830
144 A 1 1
221 A 1 2
298 A 1 3
376 A 1 4
443 A 2 4
24 V battery (12 cells)
Max constant current(A) No. of TORKEL 910 No. of TXL 830
264 A 1 1
419 A 1 2
574 A 1 3
Systems TORKEL 910 and TXL 850 (Pos 3)
48 V battery (24 cells)
Max constant current
No. of TORKEL 910 No. of TXL 850
342 A 1 1
575 A 1 2
Systems TORKEL 910 and TXL 870 (Pos 3)
110 V battery (54 cells)
Max constant current
No. of TORKEL 910 No. of TXL 870
188 A 1 1
266 A 1 2
344 A 1 3
422 A 1 4
532 A 2 4
Systems TORKEL 910 and TXL 870 (Pos 1)
220 V battery (108 cells)
Max constant current No. of TORKEL 910 No. of TXL 870
112 A 1 1
156 A 1 2
195 A 1 3
235 A 1 4
313 A 2 4
TORKEL 930
Systems TORKEL 930 and TXL 830 (Pos 3)
12V battery (6 cells)
Max constant current No. of TORKEL 930 No. of TXL 830
183 A 1 1
299 A 1 2
414 A 1 3
24V battery (12 cells)
Max constant current No. of TORKEL 930 No. of TXL 830
384 A 1 1
615 A 1 2
846 A 1 3
Systems TORKEL 930 and TXL 850 (Pos 3)
48 V battery (24 cells)
Max constant current No. of TORKEL 930 No. of TXL 850
452 A 1 1
685 A 1 2
918 A 1 3
1151 A 1 4
Systems TORKEL 930 and TXL 870 (Pos 3)
110 V battery (54 cells)
Max constant current No. of TORKEL 930 No. of TXL 870
225 A 1 1
314 A 1 2
392 A 1 3
470 A 1 4
628 A 2 4
Systems TORKEL 930 and TXL 870 (Pos 1)
220 V battery (108 cells)
Max constant current No. of TORKEL 930 No. of TXL 870
112 A 1 1
156 A 1 2
195 A 1 3
235 A 1 4
313 A 2 4
TORKEL 950
Systems TORKEL 950 and TXL 890 (Pos 1)
480 V battery (240 cells)
Max constant current No. of TORKEL 950 No. of TXL 890
65 A 1 1
70 A 1 2
90 A 1 2
100 A 1 3
120 A 2 2
