The space requirements for the
correspond to its dimensions plus at least 5
s and 10 cm behind. Above the tank should remain
clear, in order to easily fill the s
provide sufficient ventilation.
uses a
cooling system that has a cooler at the rear of the
device
The function and lifetime can be affected if heat
dissipation via the cooler is restricted.
Therefore we do not recommend incorpora
; this is only possible if sufficient air
Fig. 2: Dimensions of Vacuklav
®
41 B+/43 B+
In case of external feed water supply there is additional space required for
a water treatment unit MELAdem
Place the steam sterilizer on a flat and level surface.
The Vacuklav
®
41 B+ weighs 59 kg without load and without feed water.
The
Vacuklav
®
43 B+ weighs 66 kg without load and without feed water.
Electric circuit with 220-240 V (max. voltage range 207-253 V) and
Connected load 3400 W (at least 15 A separate fuse protection)
Connected load for UK, Ireland, Malaysia 2760 W (at least 13 A
separate fuse protection)
Protection from leakage current 30 mA
The power socket must be accessible after installation, so that the
sterilizer can be disconnected from the power supply if necessary.
The power cable is 1.35 m long.
If you want to connect a log printer to the steam sterilizer, you need
another socket for its power supply.
Wall drain or siphon drain
A wall drain, nominal width DN 40 or a siphon drain (sink drain) is required
for the one way drain
A 1 m wastewater hose (MELAG Art. No. 39180) can be ordered from
MELAG to directly connect the
steam sterilizer to the waste water, i.e. the
pressure release goes directly into the siphon of the domestic water
supply.
One way overflow
hose to siphon
If you connect the one way overflow hose from the steam sterilizer to the
siphon of the built in water system, you need a drain hose of 2 meters (Art.
No. 36585), which
you can also request from MELAG.
