7 Specifications
7.1 SN2700 Series
Feature Value
Mechanical Size: Standard depth - 1.72” (H) x 16.84” (W) x 27” (D).
43.8mm (H) x 427.83mm (W) x
686.8mm (D).
Short depth - 1.72'' (H) x 16.84'' (W) x 17'' (D).
43.9mm (H) x 428mm (W) x 432mm (D).
Mounting: 19” Rack mount
Weight: 1 PSU: 10.23kg, 2 PSUs: 11.1kg
Speed: 10/25/40/50/56/100GbE per port
Connector cage: 32 QSFP28
Environmental Temperature: Operational: 0° to 40°C
Non-Operational: -40° to 70°C
Humidity: Operational: 10% - 85% non-condensing
Non-Operational: 10% - 90% non-condensing
Altitude: 3050m
Noise level: 71.6 dB(A)
Regulatory Safety/ EMC: CB, cTUVus, CE, CU, S_Mark, CE, FCC, VCCI, ICES,
RCM, BSMI, KCC, CCC
RoHS: RoHS complaint
Power Supply
AC and DC
Input Voltage: 100-127VAC; 50/60Hz 3.5A; 200-240 50/60Hz 2.9A/
192-288VDC (not certified)
48VDC (Input voltage 40-72 VDC)
