Memmert ULE 400 - Removing temperature limiter Class P; Changing unit protection fuse

UE/BE 200-800, SE 200-400, ULE/SLE 400-800
UP/BP/ULP/SLP 400-800
8
8 Removing the temperature limiter / Class P
 Remove top cover (see chap. 1).
 Remove rear wall (chap. 15).
 Push temperature sensor (2) carefully out
of the clip with a tool and pull it up
through the intermediate plate.
 Disconnect all cable connectors (3) at the
temperature limiter (1).
 Loosen screws (4) at the rear post of the
casing cover and lift out temperature
limiter.
9 Changing the fuse for unit protection
 Remove top cover (see chap. 1).
 For changing the quick acting fuse 250V/15A push a flat screwdriver from the side
under the fuse and lift it out of its clamp by twisting the screwdriver.

Push the new fuse from above into the clamp.
4 3
1
5
2
