Engineer’s Quick Reference Programming Chart
TS400 & TS410 8 of 10 496522 Issue A
TS400 & TS410
Key Function Action LEDs On Off
1 Zone Types
Press [1] - [5] to toggle LEDs
on/off.
Press [0] to end
1
2
3
4
5
Z1 = Access
Z2 = Access
Z3 = Keyswitch
Z4 = Fire
Z5=PA
Z1 = Alarm
Z2 = Alarm
Z3 = Alarm
Z4 = Alarm
Z5 = Alarm
2 View Log
Press [1] for newest event
Press [4] for oldest event
Zone LEDs that light have caused an alarm
3 Walk Test
Activate detectors.
Press [0] to end
When the zone is in alarm the panel will sound
and the relevant zone LED will light.
4 Exit Time
Press [1] to [4].
Press [0] to end
1
2
3
4
10 seconds
30 seconds
1 minute
2 minutes
5 Entry Time
Press [1] to [4].
Press [0] to end
1
2
3
4
10 seconds
30 seconds
1 minute
2 minutes
6 Bell Duration
Press [1] - [5].
Press [0] to end
1
2
3
4
5
90 seconds
3 minutes
10 minutes
20 minutes
Continuous
7
Change Engineer's
Passcode
Enter new passcode twice
Zone LEDs1-4will light, as code is entered
each LED will go out one by one.
8 Remote Reset No. Enter reset number twice
Zone LEDs1-3will light, as code is entered
each LED will go out one by one.
9 System Options
Press [1] - [6] to toggle LEDs
on/off
Press [0] to end
1
2
3
4
5
F.Exit
Bell output = SAB
Set by Final Exit
Reset by Engineer
3 re-arms
Key = Home set
RST = SW12V
Bell output = SCB
Set by Timed Exit
Reset by User
1 re-arm
Key = Away set
RST = Det. Reset
HOME Part set the system Leave via exit route
AWAY Full set the system Leave via exit route
0 Return to unset
