MerCruiser 3.0 MPI - Page 89

Section 5 - Maintenance
90-899883272 MARCH 2008 Page 81
IMPORTANT: To ensure that the MerCathode reference electrode is not damaged, do not
paint or pressure wash.
6206
a
b
a - MerCathode controller b - MerCathode assembly
Anode Kit (if equipped) ‑ Mounted to the boat transom.
5642
Trim Cylinder Anodes ‑ Mounted on each trim cylinder.
a
7460
a - Trim cylinder anodes
