Mercury Racing HP1200 SCi Dry Sump User Manual

MAINTENANCE
63
Propellers
!
WARNING
Avoid serious injury or death. Place the remote control in neutral
and remove the ignition key from the switch before removing and/
or installing the propeller. Place a block of wood between the
anti‑ventilation plate and the propeller to protect hands from
propeller blades and to prevent the propeller from rotating when
removing the propeller nut.
!
CAUTION
Avoid propeller/sterndrive damage or injury. Periodically check
propeller nut for tightness during boating season. A minimum of
136 Nm (100 lb‑ft) torque is required.
REMOVAL
1. Place a wood block between the propeller blade and the
anti‑ventilation plate to prevent rotation. Straighten bent tabs
on tab washer.
a
b
7448
a - Wood block
b - Propeller nut
2. Turn the propeller shaft nut counter‑clockwise to remove the
nut.
