MAINTENANCE
63
10. Using an electric drill motor, manually turn the oil pump pulley
(clockwise) to prime the engine oiling system until reaching an oil
pressure of 276 kPa (40 psi).
a - Oil pump pulley
b - Clockwise direction of electric drill motor
c - Electric drill motor
11. Add any additional oil to the reservoir to bring the oil level to
approximately 25.4 mm (1 in.) below the bottom of the reservoir split
ring.
12. Install the oil pump belt and tighten the pump mounting fasteners.
Tension the oil pump belt to Specifications.
Description N lb.
Oil pump belt When the belt can be twisted with two
fingers approximately 1/4 turn.
NOTE: Engine oil level in the reservoir will increase as the engine oil
temperature increases.
