SMARTCRAFT HARNESS CONNECTION
If SmartCraft gauges are being used with the outboard, route the SmartCraft
wiring harness through the grommet and connect it to the SmartCraft harness
connector on the engine.
a - SmartCraft harness connector
WATER PRESSURE TUBE CONNECTION
If a water connection to the engine is required for a water pressure gauge,
make the connection as follows:
a
23700
OUTBOARD INSTALLATION
eng 139
