GENERAL INFORMATION

Component Identification

3403

a - Top cowl

b - Bottom cowl

c - Water pump indicator hole

d - Driveshaft housing

e - Anti-ventilation plate

f - Auxiliary tilt switch

g - Transom brackets

h - Gearcase

i - Cooling water intake holes
