MAINTENANCE
42
8. Flo-Torq II Drive Hub Propellers - Install forward thrust hub, replaceable drive sleeve, propeller,
thrust hub, propeller nut retainer and propeller nut onto the shaft.
a - Propeller nut
b - Propeller nut retainer
c - Rear thrust hub
d - Propeller
e - Replaceable drive sleeve
f - Forward thrust hub
9. Place a block of wood between gearcase and propeller and torque propeller nut to specifications.
Description Nm lb. in. lb. ft.
Propeller nut 75 55
10. Secure propeller nut by bending three of the tabs into the thrust hub grooves.
Spark Plug Inspection And Replacement
!
WARNING
Damaged spark plug boots may emit sparks which can ignite fuel vapors under the engine cowl,
resulting in serious injury or death from a fire or explosion. To avoid damaging the spark plug boots,
do not use any sharp object or metal tool to remove the spark plug boots.
1. Remove the spark plug leads. Twist the rubber boots slightly and pull off.
