OUTBOARD INSTALLATION
106 eng
2. Thread the lifting eye into the flywheel hub for a minimum of
five turns.
a - Lifting eye
3. Connect a hoist to the lifting eye.
4. Lift the outboard and place it on the boat transom.
Lifting Eye 91‑90455‑‑1
Threads into the flywheel to
remove the powerhead
assembly from the driveshaft
housing, or to lift entire engine
for removal/installation.
Steering Cable ‑ Starboard Side Routed Cable
1. Lubricate O‑ring seal and entire cable end.
3724
95
Tube
Ref No.
Description Where Used Part No.
95
2-4-C with
PTFE
O-ring seal and entire cable
end
92-802859A 1
To Next Page
