Mercury 135 Pro XS OptiMax User Manual

OUTBOARD INSTALLATION
eng 107
2. Insert steering cable into tilt tube.
3725
3. Torque nut to specification.
3727
Description Nm lb‑in. lb‑ft
Nut 47.5 35
Steering Link Rod Fasteners
IMPORTANT: The steering link rod that connects the steering
cable to the engine must be fastened using a special washer
head bolt (P/N 10‑849838) and self‑locking nylon insert locknuts
(P/N 11‑826709113). Never replace locknuts with common nuts
(nonlocking) as they will work loose and vibrate off, freeing the
link rod to disengage.
