OUTBOARD INSTALLATION
128 eng
2. Fasten clamp together with two screws.
a - Screw (2)
b - Front clamp
Oil Injection Set‑Up
FILLING THE OIL TANKS
1. Remove the fill cap from the remote oil tank and fill the tank
with the recommended oil. Install the fill cap and tighten
securely.
a - Fill cap
IMPORTANT: Do not remove the vent cap from the
engine‑mounted oil reservoir tank when filling the tank. Removal
of the vent cap may damage the threads in the oil reservoir
tank. Damaged threads may result in future oil leakage.
2. Check the oil level in the engine‑mounted oil reservoir tank.
The tank must contain at least 118 ml (4 oz) of oil prior to
starting the engine.
