OUTBOARD INSTALLATION
122 eng
a. Move the remote control handle from neutral into forward
and advance the handle to the full speed position. Ensure
that the throttle control lever is touching the throttle
control lever stop screw.
b. Slowly return the handle back to the neutral detent
position.
c. Place a mark on the shift cable against the cable end
guide.
a - Forward position mark
2. Mark the reverse position as follows:
a. Move the remote control handle into reverse and
advance the handle to the full speed position. Ensure that
the throttle control lever is touching the throttle control
lever stop screw.
b. Slowly return the handle back to the neutral detent
position.
c. Place a mark on the shift cable against the cable end
guide.
a - Reverse position mark
4355
a
4356
a
