Removes flywheel from engine. Used
for lifting powerhead/engine.
Shipping Bracket Removal
1. Remove the two top screws and loosen the two bottom screws.
2. Slide the shipping bracket off the bottom screws.
3. Tighten the bottom screws to the specified torque.
a - Shipping bracket
b - Top screws
c - Bottom screws
Description Nm lb‑in. lb‑ft
Bottom screws 7.9 70
