Alternator Drive Belt Inspection
1. Remove the three screws that fastens the flywheel cover to the engine.
Lift the flywheel cover off the engine.
a - Flywheel cover
b - Screws (3)
2. Inspect the alternator drive belt.
a - Alternator drive belt
3. Have the belt replaced by an authorized dealer if any of the following
conditions are found:
• Cracks in the back of the belt or in the base of the V grooves.
• Excessive wear at the roots of the grooves.
• Rubber portion swollen by oil.
• Belt surfaces roughened.
• Signs of wear on edges or outer surfaces of belt.
4. Install the flywheel cover with three screws. Tighten the screws to the
specified torque.
Description
Nm lb‑in. lb‑ft
Flywheel cover screws 8 71
