MAINTENANCE
eng 123
3. Straighten the bent tabs on the propeller nut retainer.
4. Place a block of wood between gearcase and propeller to
hold propeller and remove propeller nut.
5. Pull propeller straight off shaft. If propeller is seized to the
shaft and cannot be removed, have the propeller removed
by an authorized dealer.
6. Coat the propeller shaft with Quicksilver or Mercury
Precision Lubricants Anti‑Corrosion Grease or 2‑4‑C with
PTFE.
Tube
Ref No.
Description Where Used Part No.
94
Anti-Corrosion
Grease
Propeller shaft 92-802867Q 1
95
2-4-C with
PTFE
Propeller shaft 92-802859A 1
IMPORTANT: To prevent the propeller hub from corroding and
seizing to the propeller shaft, especially in saltwater, always
apply a coat of the recommended lubricant to the entire
propeller shaft at the recommended maintenance intervals and
also each time the propeller is removed.
