GENERAL INFORMATION
Component Identification
1
3
4
5
6
7
8
10
11
12
13
14
15
8
8
14
9
2
1. Top Cowl
2. Cowl Latch (Front)
3. Cowl Latch (Rear)
4. Water Pump Indicator Hose
(Tell-Tail)
5. Bottom Cowl
6. Drive Shaft Housing
7. Anti-Ventilation Plate
8. Corrosion Anode(s)
9. Cowl Mount Trim Switch
10. Wiring Harness, Fuel line and
Control Cables (Install thru bot-
tom cowl)
11. Transom Brackets
12. Trim Adjustment Bolt
13. Gear Case
14. Cooling Water Intake Holes
15. Skeg
To Next Page
