Mercury 350 MAG MPI Installation Manual

INSTALLATION MANUAL
Page 20 of 77 90-864198020
Engine Installation and Initial Engine Alignment
Models With 8 Degree Down Angle Transmissions - Velvet Drive or ZF / Hurth
1. Remove the engine cover.
2. Attach a suitable sling to lifting eyes on engine and adjust so that engine is level when
suspended.
CAUTION
Center lifting eye on top of thermostat housing is used for engine alignment only.
Do not use to lift entire engine.
77912
b
a
c
a-Front Lifting Eye
b-Rear Lifting Eye
c-Center Lifting Eye
3. Lift engine into position in boat using an overhead hoist.

Mercury 350 MAG MPI Specifications

General

Engine Type	V8
Horsepower	300 HP
Ignition	Electronic
Alternator	65 amp
Cylinders	8
Displacement	5.7 L
Fuel System	Multi-Port Fuel Injection (MPI)
Emissions	EPA Certified
