INSTALLATION MANUAL
90-864198020 Page 55 of 77
ENGINE REV-LIMITER
IMPORTANT: The engines listed in the following chart are equipped with a rpm rev-
limiter that is set to an upper (or limited) rpm amount. This limit is slightly above the
normal operating range of the engine and is designed to help prevent damage from
excessive engine rpm. When the engine reaches the rev-limit rpm, the horn will
sound. Once the rpm drop into the recommended operating rpm range, normal en-
gine operation resumes.
Model
Engine Recommended
Operating RPM Range
Rev-Limit RPM Setting
Inboard
350 Mag MPI /
350 Mag MPI Horizon
4400 - 4800 4950
MX 6.2L MPI /
MX 6.2L MPI Horizon
4600 - 5000 5150
Tow Sports
350 Mag MPI 4600 - 5000 5150
Fuel Line Connection
WARNING
Boating standards (NMMA, ABYC and others) and Coast Guard regulations must
be adhered to when installing fuel delivery system.
1. Hold the brass fuel inlet fitting with a suitable wrench and install the fuel line.
Battery
IMPORTANT: Boating industry standards (BIA, ABYC, etc.), federal standards and
Coast Guard regulations must be adhered to when installing the battery. Be sure
battery cable installation meets the pull test requirements and that positive battery
terminal is properly insulated in accordance with regulations.
IMPORTANT: It is recommended (required in some states) that battery be installed in
an enclosed case. Refer to regulations for your area.
IMPORTANT: Engine electrical system is negative (–) ground.
1. Select a battery that meets all of the following specifications:
• 12-volt marine type.
• Tapered post connectors or side terminal connectors.
IMPORTANT: Do NOT use a battery with wing nut connectors.
• Battery capacity rating of at least:
Engine
(Cyl./Type)
cid (l) Minimum Required Cranking Battery Size
V8 MPI
V8 MPI
V8 MPI
305 (5.0)
350 (5.7)
377 (6.2)
550 cca/700 mca/120 Ah
