Mercury 4 TwoStroke User Manual

Tilting Outboard
TILTING TO FULL UP POSITION
1. Stop the engine. Shift the outboard into Forward (F) gear.
2. Take hold of the top cowl grip and raise outboard to the full up position.
27023
3. Then slightly lower the motor for locking at tilt‑up position.
a - Tilt up position
b - Tilt stopper
c - Tilt lever
4. The spring loaded tilt lock lever will engage automatically and lock the
outboard in full up position.
LOWERING TO RUN POSITION
1. Raise the outboard and pull up on the tilt release lever. Gently lower
outboard down.
a - Tilt lever
b - Tilt stopper
41065
a
b
c
41066
a
b
FEATURES AND CONTROLS
26 eng
