Mercury 4 TwoStroke - Page 55

• Swivel Bracket ‑ Lubricate through fittings.
a - Co‑pilot
b - Swivel bracket
• Transom Clamp Screws ‑ Lubricate threads.
27097
NOTE: Lubricating the tiller handle bushing and shift handle detent requires
disassembly of the product. These points should be lubricated at least once a
year by an authorized dealer.
• Tiller Handle Rubber Bushing ‑ Lubricate internal diameter.
27098
• Shift Handle Detent ‑ Lubricate detent.
27099
2. Lubricate the following with Light Weight Oil.
a
b
28862
MAINTENANCE
eng 45
